File:3 longbond AltoAu 1to2 8microdistance Auto test3 2outof3Autosucess.png
Size of this preview: 800 × 450 pixels. Other resolution: 1,920 × 1,080 pixels.
Original file (1,920 × 1,080 pixels, file size: 879 KB, MIME type: image/png)
Automatic recipe with different bond lengths and constant loop height, the bonding plan describes the direction of bond eg. package to chip; chip1 to chip2. The bonding length describes how much of loop height is required.
